ATtiny48
8-bit AVR Microcontroller
Pinout:
Default
VQFN-32
Style:
GOST
Variant:
Variant 1
PDIP-28
(JEDEC MS-001, Variation BF)
Pinout
Manufacturer:
Atmel
Part number:
ATtiny48-PU
PDIP-28N (JEDEC MS-001, Variation BF)
package diagram
VQFN-32
(JEDEC MO-220, VHHD-2, T2)
Manufacturer:
Atmel
Part number:
ATtiny48-MU
Manufacturer:
Atmel
Part number:
ATtiny48-MUR
VQFN-32 (JEDEC MO-220, VHHD-2, T2)
package diagram
